M8 Waterproof Connector IP67 IP68

Get Latest Price

Min. Order:

Contact Now

Product Description

Product Attributes

Model No.: m8 circular connectors

Brand: Sejow

Origin: China

Place Of Origin: China

Species: Vga, Usb, Dvi, Hdmi, Rca, Rgb, Scart, Adapter, Din, Rj45

Application: Uhf, Audio &Amp; Video, Pcb, Fpc, Microwave, Power, Rf, Automotive

Gender: Female, Male

Contacts: 16p, 1p, 7p, 2p, 6p, 4p, 9p, 5p, 8p

Application: Industrial Automation

Cable Temperature: -40°C to + 85°C

IP Rating: IP67/ IP68

Cable Diameter: 6.0mm ±0.30mm

Cable, Note: Signal/Data transmission, By IEC 61076-2-104

Conductor Cross-section: 18AWG/20AWG/22AWG/24AWG/26AWG/28AWG

Connection 1: M5/M8/M12/M16/M23, Male/Female, straight/angle, 3/4/5/6/8/12/17-pin, A/B/D/X coded

Number Of Conductors: 2/3/4/5/6/8/12/17

Rated Voltage: 30V-250V

Rated Current (40 °C): 1A-4A (High current version up to 8A)

Cable Jacket Material, Note: Shielded/Unshielded

Cable Jacket, Material: PUR/PVC/TPU

Cable Shield/Unshielded: Aluminum foil and copper braid/Unshielded

Material Contacts: Copper gold plated

Material Cover Nut: Brass

Cable Jacket, Color: Black/Green/Blue/Yellow/Grey

Cable Length L: Any length

Packaging & Delivery

The file is encrypted. Please fill in the following information to continue accessing it

CNC Turning Parts



Product Description

M8 Industrial Connector – Precision Interconnect for Automated Systems

Designed for harsh working environments, our Industrial Connector, Waterproof Connector, and Aviation Connector products ensure stable performance under vibration, dust, and temperature variations. These connectors are widely used in industrial automation systems, machinery, and control units where reliability is critical. With robust housings, secure locking mechanisms, and high electrical performance, our solutions help reduce downtime and improve overall system efficiency

M8 Series Connector – Product Specifications

Designed in full compliance with IEC 61076-2-104 international standards, ensuring compatibility and interchangeability with globally recognized M8 interfaces used in industrial automation systems.
Rated at IP67 protection level, providing excellent resistance against dust ingress and temporary immersion in water, making it ideal for harsh and outdoor industrial environments.
Available in multiple coding options including A-Code, B-Code, and D-Code, supporting a wide range of signal, data, and fieldbus communication applications such as sensors, actuators, and Ethernet-based systems.
Configurable with 3 to 8 Pin (core) arrangements, allowing flexible adaptation to different electrical requirements and application scenarios.
Offered in both shielded and unshielded versions, ensuring reliable signal transmission while minimizing electromagnetic interference (EMI) in demanding industrial environments.
Supports customization of connector appearance and surface electroplating, including materials, colors, and plating options (such as nickel or gold plating), to meet specific application, branding, or environmental requirements.
Proven durability with 48-hour salt spray test compliance, ensuring strong corrosion resistance and long service life even in humid, marine, or chemically aggressive environments.
Designed for a wide operating temperature range from -40°C to +105°C, maintaining stable electrical and mechanical performance under extreme temperature conditions.
Robust mechanical design ensures secure locking and vibration resistance, making the connectors suitable for high-vibration applications such as transportation, machinery, and industrial automation equipment.
Widely used in applications including industrial automation, sensor and actuator connectivity, robotics, packaging machinery, and control systems, providing a compact and reliable connection solution.

FAQ

A. About Our Products & Capabilities

1. What are your main machining capabilities?

We specialize in precision CNC milling and CNC turning services. We are equipped to handle 3-axis, 4-axis, and 5-axis machining, working with materials like aluminum, brass, stainless steel, and engineering plastics to produce high-tolerance components.

2. What is your standard tolerance?

Our standard machining tolerance is ±0.01 mm. We can achieve tighter tolerances for critical features upon request and based on a design review.

3. Can you machine custom parts from my drawings?

Absolutely. We are an OEM/ODM manufacturer. Simply provide your detailed 2D drawings or 3D CAD models (e.g., STEP, IGES files), and we will manufacture the parts to your exact specifications.

B. About Ordering & Payment

4. What is your MOQ (Minimum Order Quantity)?

We are flexible. We accept both low-volume prototype orders and high-volume production runs. The MOQ can be as low as 1 piece for prototyping, and we offer competitive pricing for mass production.

5. How can I get a quote?

Please send us your drawings, along with information on material, surface treatment, and required quantity. We typically provide a detailed quotation within 1-2 business days.

6. What payment terms do you accept?

We accept T/T (Bank Transfer). A deposit is required to initiate production, with the balance paid before shipment.

C. About Shipping & Logistics

7. How do you handle shipping?

We have extensive experience in international shipping. We can ship samples and small batches via express couriers like DHL/UPS. For large production orders, we arrange sea or air freight based on your needs, with FOB, CIF, or EXW terms available.

8. What is your lead time?

For prototype orders, lead time is typically 7-15 days. For mass production, it depends on the order quantity and complexity, generally ranging from 3-5 weeks. We will provide a precise schedule with your quote.

D. About Quality & After-Sales

9. How do you ensure quality control?

Quality is integral to our process. We perform a First Article Inspection (FAI), in-process checks, and a final random inspection before shipment. We can provide inspection reports and are compliant with ISO 9001 quality management standards.

10. What if I receive defective parts?

We stand behind our quality. If any parts are found to be defective due to our manufacturing process, please notify us within 12 months of delivery with supporting evidence (photos/videos). We will promptly arrange to re-manufacture or repair the defective units.
