M8 Screw Connector Panel Mount Waterproof

M8 Screw Connector Panel Mount Waterproof

Get Latest Price

Min. Order:

Contact Now

Product Description

Product Attributes

Product Description

Other information

Product Attributes

Model No.: m8 circular connectors

Brand: Sejow

Origin: China

Place Of Origin: China

Species: Usb, Vga, Dvi, Hdmi, Rca, Rgb, Scart, Adapter, Din, Rj45, Pal, Mmcx

Application: Automotive, Rf, Power, Microwave, Fpc, Pcb, Audio &Amp; Video, Uhf

Gender: Female, Male

Contacts: 1p, 7p, 2p, 6p, 4p, 9p, 5p, 3p, 8p

Application: Industrial Automation

Cable Temperature: -40°C to + 85°C

IP Rating: IP67/ IP68

Cable Diameter: 6.0mm ±0.30mm

Cable, Note: Signal/Data transmission, By IEC 61076-2-104

Conductor Cross-section: 18AWG/20AWG/22AWG/24AWG/26AWG/28AWG

Connection 1: M5/M8/M12/M16/M23, Male/Female, straight/angle, 3/4/5/6/8/12/17-pin, A/B/D/X coded

Number Of Conductors: 2/3/4/5/6/8/12/17

Rated Voltage: 30V-250V

Rated Current (40 °C): 1A-4A (High current version up to 8A)

Cable Jacket Material, Note: Shielded/Unshielded

Cable Jacket, Material: PUR/PVC/TPU

Cable Shield/Unshielded: Aluminum foil and copper braid/Unshielded

Material Contacts: Copper gold plated

Material Cover Nut: Brass

Cable Jacket, Color: Black/Green/Blue/Yellow/Grey

Cable Length L: Any length

Product Description

M8 Industrial Connector – Precision Interconnect for Automated Systems

As a reliable partner for Industrial Connector, Waterproof Connector, and Aviation Connector applications, we focus on providing complete interconnection solutions rather than just components. Our products are designed to enhance system reliability, simplify installation, and support long-term operation. With strict quality control and application-driven design, we help engineers build stable, efficient, and scalable systems across various industries.

This M8 series connector is developed based on the IEC 61076-2-104 standard, so it can match well with most standard interfaces on the market. With an IP67 rating, it handles dust and water exposure without issues, suitable for general industrial environments.

We offer A, B, and D coding options, which can cover most signal and communication needs. Pin options range from 3 to 8 cores, making it flexible for different applications.

Both shielded and unshielded versions are available depending on your EMI requirements. The appearance and plating can also be adjusted if you have specific needs.

The connector has passed a 48-hour salt spray test and can work in temperatures from -40°C to 105°C, so it performs reliably in both normal and relatively harsh conditions.

Basic Specifications

-Pins Number: 3 4 5 6 8pins

-Plug: assembly, overmolded cable type (length can be customized )

-Most connectors are excellent for full shielding at 360 degrees

-Socket: Front Mount Solder Type, Back Mount Solder Type and PCB board type

-Waterproof grade: Ip65 IP67

-Products comply with IEC 61076-2-104 standard
