3 Pin IP67 Waterproof Connector

Get Latest Price

Min. Order:

Contact Now

Product Description

Product Attributes

Model No.: M8 Circular Connector

Brand: Sejow

Origin: China

Place Of Origin: China

Species: Usb, Vga, Mmcx, Bnc, Sma, Dvi, Hdmi, Ssma, Rca, Rgb, Adapter, Rj45, Din

Application: Automotive, Rf, Power, Microwave, Fpc, Pcb, Audio &Amp; Video, Uhf

Gender: Female, Male

Contacts: 1p, 7p, 2p, 4p, 9p, 5p, 3p, 8p

Type: Waterproof

Gender: Female and male

Pin Number: 2 3 4 5 6 8 12 17 pin

Coded: A/B/D/X

Rated Voltage: 250V

Rated Current: 4A

Contact Material: copper (gold-plated)

Insert Material: PA66+30%GF

Waterproof Degree: IP67

Temperature Range: -25~+85°C

Packaging & Delivery

The file is encrypted. Please fill in the following information to continue accessing it

Machining CNC Parts



Product Description

M8 Industrial Connector – 3 Pin IP67 Waterproof Connector

If your application involves frequent connection and disconnection, this M8 connector offers a stable and easy-to-use solution. The threading design helps keep the connection secure during operation, especially in environments with vibration. It’s often selected for automation equipment and signal transmission tasks. We can also support different cable types and lengths depending on your setup.

This M8 series connector is designed as a reliable waterproof connector for industrial automation, offering IP67 protection and stable signal transmission. Compliant with IEC61076-2-104, it supports various coding types and pin layouts. As an industrial connector, it performs well in harsh environments, and its durability also makes it suitable for applications where Aviation Connector standards are referenced. M12, M5, and M16 connectors are also available.

Basic Specifications

1. Technical Parameters
Design Standard	DIN EN 61076-2-101/109/111 (IEC)
Connector Design:	M8 Field Wireable Connector
Connector locking system:	Screw
Shielded Optional:	Unshielded or Shielded
Termination:	Panel Mount Connector
Panel Mount Conn Design:	Solder, Dip Solder, Crimping, Litz wires
Coding:	A	A	A, D	B	A	A
Contacts:	2	3	4	5	6	8
Current:	4A	4A	4A	3A	2A	1.5A
Voltage:	60V	60V	60V	30V	30V	30V
Withstanding Voltage:	800V	800V	800V	800V	800V	800V
Wire Gauge:	24AWG	24AWG	24AWG	24AWG	26AWG	26AWG
Material:	PA66, Brass Gold Plated
Mechanical Operation:	>100 Mating Cycles
Contacts Resistance:	3m Ω
Operation Temperature:	~25°C ~ 85°C
Protection Rate:	IP67
Salt Mist:	48h
All Materials meet RoHS requirements
