Product Description

Product Attributes

Model No.: M8 Circular Connector

Brand: Sejow

Origin: China

Place Of Origin: China

Species: Usb, Vga, Mcx, Bnc, Dvi, Hdmi, Din, Rj45

Application: Rf, Power, Automotive, Microwave, Fpc, Pcb, Audio &Amp; Video, Uhf

Gender: Female, Male

Contacts: 16p, 1p, 14p, 7p, 10p, 4p, 9p, 5p, 12p, 8p, 2p, 6p

Type: Waterproof

Gender: Female and male

Pin Number: 2 3 4 5 6 8 12 17 pin

Coded: A/B/D/X

Rated Voltage: 250V

Rated Current: 4A

Contact Material: copper (gold-plated)

Insert Material: PA66+30%GF

Waterproof Degree: IP67

Temperature Range: -25~+105°C

Packaging & Delivery

The file is encrypted. Please fill in the following information to continue accessing it

Machining CNC Part



Product Description

M8 Connector Cable | IP67 Waterproof | Custom Wire Harness

Our M8 connector is widely used as an industrial connector in automation and control systems where stable performance is required. Designed to IEC61076-2-104, it offers reliable IP67 sealing, making it a dependable Waterproof Connector for harsh environments. With multiple Pin configurations and coding options, it can also be adapted for applications similar to Aviation Connector requirements. We also support M12, M5, and M16 series

Built according to IEC61076-2-104, our M8 connectors offer IP67 protection. Available in A, B, and D coding, with options from 3 to 8 pins. Both shielded and unshielded versions are supported, and customization is available for appearance and plating. Tested to withstand 48-hour salt spray and designed to operate from -40°C to 105°C.

Technical date

Shell material: Copper/Zinc

Insert material: PA66+30%GF

Moulded material: PVC/TPU

Contact material: CuSn

Ambient temperature: 20°C~+105°C

Insulation resistance: >100

Contact resistance: ≤100

IP rating: IP67/P68

Standard: IEC61076-2-104
