M8 4 Pin D Coded Circular Connector

Get Latest Price

Min. Order:

Contact Now

Product Description

Product Attributes

Model No.: m8 circular connectors

Brand: Sejow

Origin: China

Place Of Origin: China

Species: Usb, Hdmi, Dvi, Adapter, Din, Rj45

Application: Uhf, Pcb, Audio &Amp; Video, Fpc, Microwave, Power, Rf, Automotive

Gender: Female, Male

Contacts: 1p, 7p, 10p, 2p, 6p, 4p, 9p, 5p, 3p, 8p

Application: Industrial Automation

Cable Temperature: -40°C to + 85°C

IP Rating: IP67/ IP68

Cable Diameter: 6.0mm ±0.30mm

Cable, Note: Signal/Data transmission, By IEC 61076-2-104

Conductor Cross-section: 18AWG/20AWG/22AWG/24AWG/26AWG/28AWG

Connection 1: M5/M8/M12/M16/M23, Male/Female, straight/angle, 3/4/5/6/8/12/17-pin, A/B/D/X coded

Number Of Conductors: 2/3/4/5/6/8/12/17

Rated Voltage: 30V-250V

Rated Current (40 °C): 1A-4A (High current version up to 8A)

Cable Jacket Material, Note: Shielded/Unshielded

Cable Jacket, Material: PUR/PVC/TPU

Cable Shield/Unshielded: Aluminum foil and copper braid/Unshielded

Material Contacts: Copper gold plated

Material Cover Nut: Brass

Cable Jacket, Color: Black/Green/Blue/Yellow/Grey

Cable Length L: Any length

Packaging & Delivery

The file is encrypted. Please fill in the following information to continue accessing it

CNC machining (8)



Product Description

Aviation-Grade M8 Connector – Threaded Locking for Vibration-Prone Applications

This M8 series adopts Aviation Connector locking principles to serve demanding Industrial Connector applications. The precision-threaded engagement prevents unmating due to mechanical vibration, a common failure mode in servo drives and high-speed pick-and-place systems. As a fully sealed Waterproof Connector, it withstands oil mist, humidity, and particulate ingress, delivering the mechanical margin engineers require for long-term deployment in automated manufacturing cells and motion control platforms.

M8 series with IP67/68 rating, provides with 2,3,4,5,6,7,8,12,14,19,24 contacts, different Pin match specific applications.

We supply full series of M8 with field wireable connector, molded cable connector, panel connector, overmoled cables, wire harness and accessories. PVC (general) or PUR (oil resistant) cables available with customized length according to user requirements.

Coding	D
Number of Positions	2/3/4/5/6/7/8/12/14/19/24
Connection Type	Single Ended Cable / Double Ended Cable
Connector type	M16 / M16 to M16
Gender	Male / Female / Male to Female / Male to Male
Gender	/ Female to Female
Orientation	Straight / Right Angle / Straight to Right Angle
Mounting Type	Cable
Termination Style	Solder Type

FAQ

A. About Our Products & Capabilities

1. What are your main machining capabilities?

We specialize in precision CNC milling and CNC turning services. We are equipped to handle 3-axis, 4-axis, and 5-axis machining, working with materials like aluminum, brass, stainless steel, and engineering plastics to produce high-tolerance components.

2. What is your standard tolerance?

Our standard machining tolerance is ±0.01 mm. We can achieve tighter tolerances for critical features upon request and based on a design review.

3. Can you machine custom parts from my drawings?

Absolutely. We are an OEM/ODM manufacturer. Simply provide your detailed 2D drawings or 3D CAD models (e.g., STEP, IGES files), and we will manufacture the parts to your exact specifications.

B. About Ordering & Payment

4. What is your MOQ (Minimum Order Quantity)?

We are flexible. We accept both low-volume prototype orders and high-volume production runs. The MOQ can be as low as 1 piece for prototyping, and we offer competitive pricing for mass production.

5. How can I get a quote?

Please send us your drawings, along with information on material, surface treatment, and required quantity. We typically provide a detailed quotation within 1-2 business days.

6. What payment terms do you accept?

We accept T/T (Bank Transfer). A deposit is required to initiate production, with the balance paid before shipment.

C. About Shipping & Logistics

7. How do you handle shipping?

We have extensive experience in international shipping. We can ship samples and small batches via express couriers like DHL/UPS. For large production orders, we arrange sea or air freight based on your needs, with FOB, CIF, or EXW terms available.

8. What is your lead time?

For prototype orders, lead time is typically 7-15 days. For mass production, it depends on the order quantity and complexity, generally ranging from 3-5 weeks. We will provide a precise schedule with your quote.

D. About Quality & After-Sales

9. How do you ensure quality control?

Quality is integral to our process. We perform a First Article Inspection (FAI), in-process checks, and a final random inspection before shipment. We can provide inspection reports and are compliant with ISO 9001 quality management standards.

10. What if I receive defective parts?

We stand behind our quality. If any parts are found to be defective due to our manufacturing process, please notify us within 12 months of delivery with supporting evidence (photos/videos). We will promptly arrange to re-manufacture or repair the defective units.
