M12 Connector 4 Wire Pinout

Get Latest Price

Min. Order:

Contact Now

Product Description

Product Attributes

Model No.: M12 Circular Connector

Brand: Sejow

Origin: China

Place Of Origin: China

Species: Usb, Vga, Dvi, Hdmi, Din, Rj45, Scart, Pal

Application: Automotive, Rf, Power, Microwave, Fpc, Pcb, Audio &Amp; Video, Uhf

Gender: Female, Male

Contacts: 1p, 7p, 10p, 2p, 6p, 9p, 5p, 3p, 8p, 12p

Application: Automotive, New Energy, Robot, Industiral, Industrial Ethernet, Profinet, Ethernet IP

Type: Waterproof Connector

Rated Current: 4 A, 2 A

Rated Voltage: 250 V

IP Level: IP67 / 68

Contact Material: Copper Gold Plating

Housing Material: Brass nickel-plated/Zinc alloy nickel-plated/PA-GF

Gender: Female / Male

Shape: Round

Number Of Pins: 2,3,4,5,6,8,12,17pin

Current Rate: 1.5A/2A/4A

Cording: A/B/C/D

Insulator Material: PA+GF/TPU

Type Of Connection: Screw/ solder connection

Molding Material: TPU/PVC

Sealing Material: Epoxy resin/Rubber

Temperature Range: -25°C ~ +85°C

Packaging & Delivery

The file is encrypted. Please fill in the following information to continue accessing it

CNC Turning Parts



Product Description

M12 Male / Female Connectors - The Triple-Threat Industrial Solution

The M12 Series delivers precision-engineered connections for small sensors and actuators in demanding industrial networks. Whether you need factory over-molded TPU cables, panel receptacles with solder-cup contacts, or field-attachable solutions, our connectors provide the reliability of aerospace-inspired design with the practicality of true waterproof protection.

Pin Range: 3-12 pins (custom configurations available)

Orientation: Straight or Angled

Shielding: Shielded or Un-Shielded options

Technical Specifications

Type: Waterproof Connector

Rated Current: 1.5A-16A

Rated Voltage: 30V-60V

IP Level: IP67/IP68

Contact Material: Brass

Housing Material: Brass

Gender: Male/Female

ShapeL: Circular

Model Number: M12

Engagement force: ≤50N

Disengagement force: ≥5N

Mechanical lifespan: ≥500

Insulation resistance: ≥1000MΩ

Contact resistance: ≤10mΩ

Operation Temperature: -40℃~+105℃
