M8 Waterproof Circular Connector Cable Assembly

M8 Waterproof Circular Connector Cable Assembly

Name: Precision CNC Machining Parts
Uploaded: 2025-05-23T01:30:34+08:00
Description: M8 Circular Connector M8 sensor 3/4/5/6/8pin deutsch waterproof connector solder ip67 connector M8 Pre-molded PVC

Get Latest Price

Min. Order:

Contact Now

Product Description

Product Attributes

Model No.: M8 Circular Connectors

Brand: Sejow

Origin: China

Place Of Origin: China

Species: Usb, Vga, Hdmi, Rca, Adapter, Din, Rj45, Ssma

Application: Automotive, Rf, Power, Microwave, Fpc, Pcb, Audio &Amp; Video, Uhf

Gender: Female, Male

Contacts: 1p, 7p, 2p, 6p, 4p, 9p, 5p, 3p, 8p

Application: Industrial Automation

Cable Temperature: -40°C to + 85°C

IP Rating: IP67/IP68

Cable: PUR/PVC/Shielded/Unshielded, any length

Cable Diameter: 6.0mm ±0.30mm

Cable, Note: Signal/Data transmission, By IEC 61156-6

Conductor Cross-section: 18AWG/20AWG/22AWG/24AWG/26AWG/28AWG

Connection 1: M5/M8/M12/M16/M23, Male/Female, straight/angle, 3/4/5/6/8/12/17-pin, A/B/D/X coded

Number Of Conductors: 2/3/4/5/6/8/12/17

Rated Voltage: 30V-250V

Rated Current (40 °C): 1A-4A (High current version up to 8A)

Cable Jacket Material, Note: Shielded/Unshielded

Cable Jacket, Material: PUR/PVC/TPU

Cable Shield/Unshielded: Aluminum foil and copper braid/Unshielded

Material Contacts: Copper gold plated

Material Cover Nut: Brass

Cable Jacket, Color: Black/Green/Blue/Yellow/Grey

Cable Length L: Any length

Packaging & Delivery

The file is encrypted. Please fill in the following information to continue accessing it

Precision CNC Machining Parts



Product Description

M8 Circular Connector

M8 sensor 3/4/5/6/8pin deutsch Waterproof Connector solder ip67 connector M8 Pre-molded PVC cable connectors with 12mm thread locking mechanism, rated IP67 protection degree,contacts configuration is 6 poles. 360°EMC shielding is available for option. Compliant with IEC 61076-2-101 and mainly designed for signal transmission.

• M8 Circular connector according to IEC 61076-2-104

• M8 circular connector with M8*1.0 Screw locking

• Equivalent to Binder, Phoenix, Lumburger automation

• Waterproof rating is IP67/IP68, protected from dust and water during immersion, resistant to many oils and chemical

1. Cable length: customize

2. Degree of protection IP 67

3. 5 poles per connector is available

4. Operating voltage 60V; Current range: 4A

5. Anti-vibration locking screw design

Product name	M8 shielded Plug 5 Pin B-coding
Ratings	Voltage: 30 V
Ratings	Current: 3 A
Operating Temperature Range	-40 ~ 105 °C
Materials	1. Insulator: PA66glass fiber, UL94 HB, black
	2. Pin: phosphor copper, gold plated
	3 . Inner shielding: Zinc aluminum alloy, nickel plated
	4 .Shell: C3604 brass, nickel plated
	5 .O-ring: Nitrile rubber, black
Electrical Requirements	1.Dielectric strength: 1 min @ 500 Vac 2.Insulation resistance: 100 MΩ @ 500 Vdc 3.Contact resistance: 10 mΩ or less


Mechanical Requirements	Life cycle: 1000 mating cycles minimum
Environmental Requirements	Salt spray test: 35 °C, relative humidity 90-95%, 5% NaCl mist for 48 hrs. Wash parts after test. Maintain mechanical requirements and a contact resistance of less than 10 mΩ.


Waterproof	IP67
Assembly Info	Wire gauge: 24 AWG max
Certificate	CE,ISO9001,RoHS
