Industrial Push Pull & Threaded Connectors - Reliable
Industrial Push Pull & Threaded Connectors - Reliable
Industrial Push Pull & Threaded Connectors - Reliable
Industrial Push Pull & Threaded Connectors - Reliable
Industrial Push Pull & Threaded Connectors - Reliable
Industrial Push Pull & Threaded Connectors - Reliable
Industrial Push Pull & Threaded Connectors - Reliable
Industrial Push Pull & Threaded Connectors - Reliable

Industrial Push Pull & Threaded Connectors - Reliable

Get Latest Price
Min. Order:1
Product Attributes

Model No.M5 Circualr Connector

BrandSejow

SpeciesUsb, Vga, Dvi, Hdmi, Rca, Rgb, Scart, Adapter, Din, Rj45, Sma

ApplicationAutomotive, Rf, Power, Microwave, Fpc, Pcb, Audio &Amp; Video, Uhf

GenderMale, Female

Contacts1p, 16p, 7p, 10p, 2p, 6p, 4p, 9p, 5p, 3p, 12p, 8p, 18p, 20p, 14p, 22p, 26p, 24p, 64p, 32p, 28p, 50p, 34p, 30p, 36p, 40p

ApplicationAutomotive, Data Communication, Electrical, Microwave, PCB, Wire Connections

GenderMale Female

TypeM3 M5 M8 M12 M16 M23

OrientationStraight / Right Angle

Shell Size8S,10S,10SL,12S,14S,16,18,20,22,24,28,32, 36,40,44,48

Shell MaterialAluminum alloy / Copper alloy / Stainless steel

Housing MaterialNickel plated brass

Contact MaterialCopper Alloy

Pin1 - 64 pin

InsulatorSynthetic Rubber

ServiceOEM / ODM

Place Of OriginChina

Packaging & Delivery

The file is encrypted. Please fill in the following information to continue accessing it

CNC Encoder Housing
Product Description
                                                              Professional Waterproof & Electrical Connectors Manufacturer

Sejow specializes in high-performance electrical connectors and cable assemblies, delivering robust solutions for demanding applications. Our product range includes critical connector types such as Industrial Connectors for heavy-duty machinery, aviation connectors for aerospace safety, and fully sealed waterproof connectors for harsh environments. Renowned for ease of use, ruggedness, and reliability, our products serve diverse sectors including 5G infrastructure, automotive systems, green energy, medical devices, test and measurement, marine technology, nuclear facilities, oil and gas operations, and motorsport. Each connector is engineered to ensure maximum durability and dependable performance in the most critical conditions.

Key Parameters of M5 Connectors:

Feature: Typical Parameters / Description
Thread Specification: M5 x 0.5 (5mm diameter, 0.5mm pitch)
Protection Rating: Typically IP67 (dustproof, short-term immersion), some can reach IP68/IP69K. This is a key selection criterion!
Rated Current: Low, typically between 0.5A and 2A (depending on the number of pins and materials). Not suitable for power transmission.
Rated Voltage: Commonly 30V - 60V.
Number of Contacts: Mainstream are 3-Pin and 4-pin, also available in 2-pin and 5-pin. 3-pin (power+, power-, signal), 4-pin (one more signal line or used as simple two twisted pairs).
Contact Type: Pin/socket, usually crimp type for easy field installation. Pre-molded cable assemblies are also available.
Insulation Material: PA (nylon, commonly used), PBT (more heat resistant)
Housing Material: Nickel-plated brass (economical, commonly used), stainless steel (higher corrosion resistance, used in food and chemical environments)
Locking Method: Threaded locking, ensuring stability in vibrating environments. Some manufacturers offer variants with push-pull self-locking function for quick insertion and removal.
Common Cable Outer Diameter: The outer diameter of the matching cable is usually between 3mm and 5mm, very flexible and compact.
Operating Temperature: -25°C to +85°C

M ConnectorWaterproof ConnectorFemale ConnectorGender ConnectorIndustrial ConnectorIP67 ConnectorAviation Connector
